The 2026 GMC Sierra 2500 HD and 3500 HD are engineered for Canadian owners who demand maximum hauling and trailering capability. With multiple configuration options and specialized towing hardware, these heavy-duty trucks deliver the performance needed for demanding work sites and recreational towing. This guide breaks down the towing capacities, payload ratings, and specialized hardware that make the Sierra HD lineup a serious contender for heavy-duty applications across Ontario.
Whether you're hauling construction equipment, towing a fifth-wheel trailer, or managing a commercial fleet, understanding the differences between the 2500 HD and 3500 HD models - and choosing the right hitch configuration - ensures you maximize capability while staying within safe operating limits.
|
Specification |
Sierra 2500 HD AT4 (SRW) |
Sierra 3500 HD AT4 (SRW) |
|
Max GCWR |
13,608 kg (30,000 lb) |
13,608 kg (30,000 lb) |
|
Max Conventional Trailering |
9,072 kg (20,000 lb) |
9,072 kg (20,000 lb) |
|
Max Gooseneck/Fifth-Wheel |
9,612 kg (21,190 lb) |
9,662 kg (21,300 lb) |
|
Max Payload |
1,598 kg (3,524 lb) |
1,871 kg (4,127 lb) |
|
Cargo Volume |
1,968-2,364 L |
1,968-2,364 L |
The 2026 Sierra HD lineup offers two engine options designed for different heavy-duty applications. The 6.6L V8 gasoline engine is paired with a 10-speed automatic transmission, delivering consistent torque across the rev range. This powertrain is well-suited for towing heavy loads at highway speeds and managing steep grades.
The Duramax 6.6L Turbo-Diesel V8 is the foundation of the Sierra HD's maximum towing capabilities. This diesel engine provides the torque characteristics needed for sustained heavy hauling, particularly in gooseneck and fifth-wheel configurations. The 10-speed automatic provides close gear ratios, allowing both engines to stay in their optimal power bands during acceleration and maintaining momentum when hauling trailers.
The hydraulic power-assisted Hydroboost brake system delivers strong stopping force, with four-wheel disc brakes featuring 355 mm front rotors and 360 mm rear rotors on SRW models. ABS and Stabilitrak electronic stability assist are standard across the lineup.
The Sierra HD's Gross Combined Weight Rating (GCWR) offers the total allowable weight of the truck, all cargo, passengers, fuel, and the trailer being towed. The AT4 and AT4X trims offer a maximum GCWR of 13,608 kg (30,000 lb), though higher GCWR ratings are available on other HD configurations - particularly 3500 HD DRW models equipped with the Duramax diesel engine.
Conventional towing uses a standard hitch receiver and ball mount, with a maximum rating of 9,072 kg (20,000 lb) on both the 2500 HD and 3500 HD AT4 models. This configuration is ideal for travel trailers, equipment trailers, and enclosed cargo trailers where the tongue weight is distributed over the rear axle.
Gooseneck and fifth-wheel configurations shift the hitch point forward into the truck bed, positioning the load over the rear axle for improved weight distribution and stability. The Sierra 2500 HD AT4 offers a maximum gooseneck/fifth-wheel rating of 9,612 kg (21,190 lb), while the 3500 HD AT4 increases that capacity to 9,662 kg (21,300 lb). This makes the 3500 HD the stronger choice for large fifth-wheel RVs or heavy equipment trailers.
Payload capacity measures the total weight the truck can carry in its bed and cab, including passengers, cargo, and tongue weight from a trailer. The Sierra 2500 HD AT4 offers a maximum payload of 1,598 kg (3,524 lb), while the 3500 HD AT4 increases that rating to 1,871 kg (4,127 lb).
The 3500 HD's higher payload rating is particularly valuable when towing with a gooseneck or fifth-wheel hitch, as these configurations transfer 15-25% of the trailer's weight onto the truck bed. For example, towing a 9,072 kg (20,000 lb) fifth-wheel trailer can place approximately 1,814 kg (4,000 lb) of tongue weight on the truck - making the 3500 HD's extra payload capacity essential for staying within safe operating limits.
Cargo volume ranges from 1,968 to 2,364 litres depending on bed length, providing ample space for tools, equipment, and supplies. The GMC MultiPro Tailgate, now available on SLT trims, adds six functional configurations including a load stop, step, and workspace - making it easier to load and secure cargo.
The ProGrade Trailering System is available across the Sierra HD lineup and includes features designed to simplify heavy-duty towing. Hitch View provides a camera view of the hitch area, making it easier to align the ball mount with the trailer coupler. The system also includes trailer brake controller integration and trailer sway control, which applies selective braking to help stabilize the trailer during crosswinds or sudden maneuvers.
Digital Variable Steering Assist is standard on SLT, AT4, Denali, and Denali Ultimate trims. This system adjusts steering effort based on vehicle speed and load, providing lighter effort during low-speed maneuvers and increased feedback at highway speeds. When towing heavy trailers, this feature helps reduce driver fatigue during long hauls.
On SLT trims and above, the 13.4-inch diagonal multicolour touchscreen and 12.3-inch diagonal Driver Information Centre provide real-time trailer monitoring, including tire pressure, brake output, and trailer weight distribution. These displays help drivers stay informed about trailer conditions without needing to pull over for manual checks.
The Sierra HD uses a short-long-arm independent front suspension with torsion bars, providing a balance between ride comfort and load-carrying capability. The rear suspension features semi-elliptic, two-stage, multi-leaf springs on the 2500 HD, with three-stage springs on the 3500 HD and 2500 HD models equipped with the Max Towing Package.
Ground clearance measures 257 mm (10.1 inches) on the 2500 HD AT4 and increases to 283-284 mm (11.1-11.2 inches) on the 3500 HD AT4, providing additional clearance when navigating uneven terrain or steep approach angles with a loaded trailer. Wheelbase ranges from 4,037 to 4,369 mm (159.0 to 172.0 inches), with overall length spanning 6,369 to 6,776 mm (250.8 to 266.8 inches) depending on cab and bed configuration.
The 2026 Sierra HD is available in seven trim levels: Pro, SLE, SLT, AT4, AT4X, Denali, and Denali Ultimate. Each trim offers distinct feature sets, with higher trims adding luxury appointments, advanced technology, and enhanced off-road capability.
The AT4 and AT4X trims are offered exclusively in 4WD Crew Cab configurations, with AT4 available in both 2500 HD and 3500 HD SRW, and AT4X available in 2500 HD only. These trims include off-road-focused features such as skid plates, all-terrain tires, and tuned suspension components. Other HD configurations - including Regular Cab and Double Cab models - are available in both 2WD and 4WD.
Wheel options range from 17-inch steel wheels on base trims to 22-inch aluminum wheels on select 2500 HD configurations. Tire sizes vary by model and trim, with options including LT275/70R18E all-terrain tires on most 2500 HD and 3500 HD models, and LT235/80R17E all-terrain tires on 3500 HD DRW configurations.
Conventional towing is suitable for most recreational and light commercial applications, including travel trailers, boat trailers, and equipment trailers under 9,072 kg (20,000 lb). The hitch receiver mounts to the rear frame, and the ball mount extends behind the bumper, providing easy hookup and a wide turning radius.
Gooseneck and fifth-wheel towing are designed for heavier loads and applications where stability is critical. The hitch point is located in the truck bed, directly over the rear axle, which reduces trailer sway and improves handling during emergency maneuvers. This configuration is preferred for large fifth-wheel RVs, heavy equipment trailers, and commercial hauling applications.
When choosing between the 2500 HD and 3500 HD, consider your typical trailer weight and tongue weight. If you regularly tow near the maximum conventional rating of 9,072 kg (20,000 lb) or exceed 9,612 kg (21,190 lb) with a gooseneck setup, the 3500 HD's higher payload capacity provides additional margin for safe operation.
The Sierra 2500 HD is well-suited for drivers who need strong towing capability but do not regularly operate at maximum GCWR. Its 9,612 kg (21,190 lb) gooseneck rating and 1,598 kg (3,524 lb) payload capacity handle most recreational and light commercial towing applications.
The Sierra 3500 HD is the preferred choice for drivers who frequently tow heavy fifth-wheel trailers, transport large equipment, or operate near maximum GCWR. Its 9,662 kg (21,300 lb) gooseneck rating and 1,871 kg (4,127 lb) payload capacity provide the extra margin needed for demanding applications.
Both models share the same 9,072 kg (20,000 lb) conventional towing rating, making the decision primarily about payload capacity and how you plan to use the truck.
The 2026 GMC Sierra 2500 HD and 3500 HD deliver the towing capacity, payload ratings, and specialized hardware needed for heavy-duty work and recreational towing. Whether you're choosing between conventional and gooseneck configurations or deciding between the 2500 HD and 3500 HD, understanding these specifications ensures you select the right truck for your needs.
